3753#【PDF 1/1 页】SHIELDED BOX BULK

Model 3753

Miniature Size Aluminum Box

with Cover

MATERIALS (item included ):

Housing : Die cast aluminum, alloy A380 or A384.

- Finish: Blue baked enamel paint per Federal Standard 595 #25109 over Phosphoric Etch

Cover : .040” (1,01mm) thick aluminum #1100-H14

- Finish: Clear anodized

Screws : Steel, 4 ea. #2-32 x ?” Pan-held self-tapping.

ORDERING INFORMATION: Model 3753

Replacement and optional items:

Model 4742

Model 4864

Model 2352

Model 3729

Replacement Cover

Replacement Cover Screws (100/pkg)

Connector Screws with Turret

Flange Mounting Cover

Optional Box Variations:

Model 3754

Model 3751

Model 3752

Die cast aluminum not finished

BNC (f), and BNC (f ), one on each end.

BNC (m), and BNC (f), one on each end.

All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (,51 mm), .xxx = ± .005” (,127 mm).

All specifications are to the latest revisions. Specifications are subject to change without notice.

Registered trademarks are the property of their respective companies.

Sales: 800-490-2361 Fax: 888-403-3360 Technical Assistance: 800-241-2060

For “Where to Buy” information, visit the Pomona web site at www.pomonaelectronics.com

Rev: 101

D1093978

Page 1 of 1
